led down light(PL-COB-E01)

cob led down light
led down lights
cob down light
led down lighting

COB LED Downlight SAA Approval Australia Standard, LED Down Light, LED Spot Down Light

Parameter table

Model	Power(W)	CCT	Lumen±10%	Ra	Chip	Beam Angle	Material	LAMPSize(mm)	Voltage	PF
PL-COB-6W-E01	6W	2700K 3000K 4000k 6000k	420lm	>80	COB Epistar G20-H0112-0604	30°	ADC12 Aluminum Housing 1070Aluminum Cold Forging Heatsink	Ø95*H59 Cuthole:Ø70(2.75")	220-240V 100-277V	>0.95
PL-COB-10W-E01	10W	2700K 3000K 4000k 6000k	700lm	>80	COB Epistar G18-H0212-1208	30°	ADC12 Aluminum Housing 1070Aluminum Cold Forging Heatsink	Ø95*H81 Cuthole:Ø70(2.75")	220-240V 100-277V	>0.95
PL-COB-12W-E01	12W	2700K 3000K 4000k 6000k	840lm	>80	COB Epistar G18-H0212-1208	24° 36°	ADC12 Aluminum Housing 1070Aluminum Cold Forging Heatsink	Ø111*H88 Cuthole:Ø80(3.15")	220-240V 100-277V	>0.95
PL-COB-15W-E01	15W	2700K 3000K 4000k 6000k	1050lm	>80	COB Epistar G18-H0412-2415	15/24/ 38/60°	ADC12 Aluminum Housing 1070Aluminum Cold Forging Heatsink	Ø119*H103 Cuthole:Ø90(3.54")	220-240V 100-277V	>0.95
PL-COB-20W-E01	20W	2700K 3000K 4000k 6000k	1600lm	>80	COB Epistar G21-H0512-3018	24/60°	ADC12 Aluminum Housing 1070Aluminum Cold Forging Heatsink	Ø142*H118 Cuthole:Ø110(4.33")	220-240V 100-277V	>0.95
PL-COB-25W-E01	25W	2700K 3000K 4000k 6000k	2000lm	>80	COB Epistar G21-H0512-3018	24/60°	ADC12 Aluminum Housing 1070Aluminum Cold Forging Heatsink	Ø142*H118 Cuthole:Ø110(4.33")	220-240V 100-277V	>0.95
PL-COB-30W-E01	30W	2700K 3000K 4000k 6000k	2400lm	>80	COB Epistar G21-H0612-3622	15/24 38/60°	ADC12 Aluminum Housing 1070Aluminum Cold Forging Heatsink	Ø180*H129 Cuthole:Ø145(5.7")	220-240V 100-277V	>0.95
PL-COB-40W-E01B	40W	2700K 3000K 4000k 6000k	3200lm	>80	COB Epistar G17-H0512-3018	24/60°	ADC12 Aluminum Housing 1070Aluminum Cold Forging Heatsink	Ø193*H129 Cuthole:Ø158(6.22")	220-240V 100-277V	>0.95
PL-COB-50W-E01	50W	2700K 3000K 4000k 6000k	4000lm	>80	COB Epistar G17-H0812-4829	24/60°	ADC12 Aluminum Housing 1070Aluminum Cold Forging Heatsink	Ø193*H129 Cuthole:Ø158(6.22")	220-240V 100-277V	>0.95
PL-COB-60W-E01	60W	2700K 3000K 4000k 6000k	5400lm	>80	COB Epistar G17-H0812-4829	24/60°	ADC12 Aluminum Housing 1070Aluminum Cold Forging Heatsink	Ø193*H149 Cuthole:Ø158(6.22")	220-240V 100-277V	>0.95
